Dunham-Bush Float & Thermostatic Steam Trap - 1-1/2"
Install trap level and support it without strain below apparatus to be dripped, but above return, assuring gravity flow of condensate and air to and from trap. A scale pocked should always be provided ahead of trap and a strainer is recommended to prevent dirt from interfering with proper operation of trap. Trap strainer and scale pocket should be located where accessible for inspection and cleaning.
• 44-715
• 15 PSI differential pressure
• 4 Port trappings (2 inlets, 2 outlets)
• Can be piped in and out from either side
• Made in the USA
• For California Residents please see Prop 65 Warnings
• 44-715
• 15 PSI differential pressure
• 4 Port trappings (2 inlets, 2 outlets)
• Can be piped in and out from either side
• Made in the USA
• For California Residents please see Prop 65 Warnings
Manufacture Item Number | ML9624 |
UPC | 703765961264 |
Weight | 1 |
Package Quantity | EACH |
Size (in) | 1-1/2 |
Details
Install trap level and support it without strain below apparatus to be dripped, but above return, assuring gravity flow of condensate and air to and from trap. A scale pocked should always be provided ahead of trap and a strainer is recommended to prevent dirt from interfering with proper operation of trap. Trap strainer and scale pocket should be located where accessible for inspection and cleaning.
• 44-715
• 15 PSI differential pressure
• 4 Port trappings (2 inlets, 2 outlets)
• Can be piped in and out from either side
• Made in the USA
• For California Residents please see Prop 65 Warnings
• 44-715
• 15 PSI differential pressure
• 4 Port trappings (2 inlets, 2 outlets)
• Can be piped in and out from either side
• Made in the USA
• For California Residents please see Prop 65 Warnings
