Taco Cast Iron Circulator Pump with IFC - 115 Volts, 1/8 HP
Taco 0011-F4-2IFC Circulator Pump with IFC (Integral Flow Check) is designed for high head and medium flow applications, that are common for large residential and light commercial applications, such as closed loop hydronic heating. The IFC built into the circulator eliminates the need for purchase and installation of an additional in-line check valve and performs better when compared to regular check valves. Taco 0011-F4-2IFC Circulator is perfect for boilers with high pressure drop, as well as fan coil units, heat exchangers, large radiant heat and heat recovery/geothermal systems. Universal flange to flange dimensions and flange orientation of the circulator allows it to serve as a replacement for other models. Compact, has low power consumption and ideal for high-efficiency jobs. Both IFC and cartridge are easily accessed for service, saving the need for replacing the entire circulator.
• Integral Flow Check (IFC) , Prevents gravity flow, Eliminates separate in-line flow check, Reduces installed cost, easy to service, Improved performance vs. In-line flow checks.
• Quiet and efficient operation.
• Field serviceable.
• Direct drive.
• Low power consumption.
• Self-lubricating.
• No mechanical seal.
• Unmatched reliability and maintenance-free.
• Wide range of applications.
• Flanged connection.
• Temperature range: 40°F to 230°F.
• Connection size: 3/4", 1-1/4", 1-1/2", and 1".
• Cast iron.
• Max pressure (PSI): 125
• 115 Volts.
Applications:
• High Pressure Drop Boilers.
• Medium/Large Hydronic, Geothermal and Radiant Heating projects.
• Wood Boilers / Furnaces.
• Hydro-Air Fan Coils.
• And many others.
Replacement Parts List:
• Casing O-Ring: 009-028RP
• Flange gasket set: 007-007RP
• Capacitor or PC Board: 009-018RP
• Cartridge assembly complete: 0011-009RP
• Valve assembly trans/relay: 0012-021RP
• For California Residents please see Prop 65 Warnings
• Integral Flow Check (IFC) , Prevents gravity flow, Eliminates separate in-line flow check, Reduces installed cost, easy to service, Improved performance vs. In-line flow checks.
• Quiet and efficient operation.
• Field serviceable.
• Direct drive.
• Low power consumption.
• Self-lubricating.
• No mechanical seal.
• Unmatched reliability and maintenance-free.
• Wide range of applications.
• Flanged connection.
• Temperature range: 40°F to 230°F.
• Connection size: 3/4", 1-1/4", 1-1/2", and 1".
• Cast iron.
• Max pressure (PSI): 125
• 115 Volts.
Applications:
• High Pressure Drop Boilers.
• Medium/Large Hydronic, Geothermal and Radiant Heating projects.
• Wood Boilers / Furnaces.
• Hydro-Air Fan Coils.
• And many others.
Replacement Parts List:
• Casing O-Ring: 009-028RP
• Flange gasket set: 007-007RP
• Capacitor or PC Board: 009-018RP
• Cartridge assembly complete: 0011-009RP
• Valve assembly trans/relay: 0012-021RP
• For California Residents please see Prop 65 Warnings
| Manufacture Item Number | 0011-F4-2IFC |
| UPC | 687752556100 |
| Weight | 9.9 |
| Package Quantity | EACH |
